Long Head Cone

Long Head Cone


Our LH series cone crushers are specifically designed for secondary applications.

Unlike conventional technology to use the same cone for secondary and tertiary applications, our LH cones have specially designed concave and mantle profiles  that can accept large feed size (upto 300mm feed) with high throughputs of 300 TPH. LH cones are ideal for accepting large size lumps out of primary jaw and produce good quality Railway ballast, coarse grade material for steel plants as well as provide good quality feed for tertiary cone crushers.

  • Built-in Rotary feed distributor that distributes the feed material 360° around the crushing chamber
    • Minimizes voids between larger stones thereby increasing Capacity
    • Uniform crushing increases concave, mantle wear life
  • Easy to customize output size with automatic hydraulic adjustment button
  • Combined power pack with Hydraulic CSS adjustment, tramp iron release system and automatic oil lubrication


Model LH200EC LH200C LH200M
Max.Capacity 250-320 200-270 160-220
Max Power 150kW / 200HP 150kW / 200HP 150kW / 200HP
Total Weight 15.5 T 15.5 T 15.5 T
